35KV及以下铜、铝芯电力电缆
10KV及以下煤矿用阻燃电力电缆
日期:08-20
标 准: 产品按国家煤炭行业标准MT818-1999制造,适用于交流供、配电系统。
Standard: The product applied for A.C. Systems of power supply and power distribution is manufactured according to the standard of mine industry MT818-1999.
工作条件:
电缆导体的允许长期高工作温度为70℃。
Max.permissible continuous operating temperature of conductor : 70℃.
短路时(长持续时间不超过5S)电缆导体的高温度不超过160℃。
Max.short-circuit temperature of the conductor shall not exceed 160℃(5s maximum duration) 煤矿用额定电压10KV及以下铜芯交联聚乙烯绝缘固定敷设阻燃电力电缆
Copper Conductor XLPE Insulated, fixed-installed, Fire-retardent power cable of rated Voltage up to and including 10KV for coal mine
